PS4 Playstation 4 HDMI Controller IC Chip Replacement MN86471A

Have you been told by another service provider that your console is unrepairable due to a motherboard fault? Then this is the repair for you - and it is repairable!

What causes the PS4 HDMI IC Chip fault?

This has always been a repair that we have carried out, but recently has become more and more common. Because we are seeing this more often in recent times with older consoles, we are putting it down to an age related chip failure.

We also see this fault happening a lot with newer consoles with customers who regularly move their PS4 around, or switch the outputs. Some customers who only use one HDMI cable with their TV will change it between the PS4 and a set top box for example.  This constant swapping of the cable seems to have an effect on the chips failing too.

How do we repair the PS4 HDMI Chip?

To repair this fault we need to carefully strip the console down to the motherboard. From there we will inspect the HDMI port to make sure it isn't damaged, and could therefore be the fault. If it is, the repair is slightly cheaper CLICK HERE for the PS4 HDMI Port Replacement Repair.

The Playstation 4 HDMI Controller IC Chip MN86471A is covered by a shield on the motherboard so we need to carefully remove this. Once we have, we will have access to the HDMI controller chip.

The chip is surface mounted so we carefully de-solder the chip from the motherboard. We then clean up the solder pads and inspect their integrity.

We then place the new PS4 HDMI chip on the motherboard and solder it down. We use a top of the range soldering iron, good flux and a microscope to ensure the job is done well.

We then reassemble the console ready for testing.
